HM62256ALP-10 Product details 32,768-word ×8-bit High Speed CMOS Static RAM The Hitachi HM62256A is a CMOS static RAM organized 32-kword ×8-bit. It realizes higher performance and low power consumption by employing 0.8 µm Hi-CMOS process technology.
Non-returnable
₹150.00
Product Details
Product Details
Product Details
HM62256ALP-10 Product details
- High speed: Fast Access time 85/100/120/150 ns (max)
- Low Power Standby: 5 µW (typ) (L/L-SL version) ...
- Single 5 V supply
- Completely static memory No clock or timing strobe required
- Equal access and cycle times
- Common data input and output: Three state output
- Directly TTL compatible: All inputs and outputs
- Capability of battery back up operation
